Using eBPF in Flatcar Container Linux

Extended Berkeley Packet Filter (eBPF) is a core Linux technology with multiple applications in different computer domains like security, networking and tracing. For the containers and Kubernetes specific case, it’s used with networking projects like Cilium or Calico, debugging solutions like BCC, kubectl-trace and Inspektor Gadget, and security-related projects like tracee and Falco.

eBPF is a very fast evolving technology: each new kernel release includes new features, and different Linux distributions rush to enable them for their users. Flatcar Container Linux is no exception, and in this blog post I cover the new eBPF features that we have enabled in the lastest Flatcar versions and why they are important.

Since Flatcar is an immutable OS, i.e the system partition is read only, we’ll use toolbox to create a dev environment where we can install the dependencies and tools we need without affecting the host in some of the examples; in others we will use Docker.

CONFIG_IKHEADERS

This option is used to expose the kernel headers through a kernel module. When the module is loaded, it creates the /sys/kernel/kheaders.tar.xz file with the kernel headers in a compressed format that can be uncompressed to a temporary location to be used by the different tools when compiling eBPF programs. This option is beneficial because it avoids installing the kernel headers on the host and also having to share the system folder containing the headers with containers.

This option is already available in the Flatcar Container Linux Stable release.

BCC supports this feature, so it is possible to run BCC tools without installing the kernel headers on the host when the kernel is compiled with CONFIG_IKHEADERS. Let’s try it out!

In order to get a Flatcar instance running on your computer with qemu you can follow the next steps. You can also get a running instance on any of the various cloud providers that Flatcar supports.

$ wget https://stable.release.flatcar-linux.net/amd64-usr/current/flatcar_production_qemu_image.img.bz2
$ bzip2 -d flatcar_production_qemu_image.img.bz2
$ wget https://stable.release.flatcar-linux.net/amd64-usr/current/flatcar_production_qemu.sh
$ chmod +x flatcar_production_qemu.sh
$ ./flatcar_production_qemu.sh

Now, you can login in the VM with

$ ssh -o "UserKnownHostsFile=/dev/null" -o "StrictHostKeyChecking=no" -p 2222 core@localhost
Warning: Permanently added '[localhost]:2222' (ECDSA) to the list of known hosts.
Last login: Mon Apr 19 13:59:55 UTC 2021 from 10.0.2.2 on pts/1
Flatcar Container Linux by Kinvolk stable (2765.2.2)
core@localhost ~ $

Let’s check that the IKHEADERS config is actually set

core@localhost ~ $ zgrep CONFIG_IKHEADERS /proc/config.gz
CONFIG_IKHEADERS=m

Before creating the toolbox environment, let’s load the kheaders kernel module. We do it that way to avoid having to mount the folders containing the kernel modules into the toolbox environment we create below. If we mount the kernel modules folder then this step is not needed and the BCC tool will load the module automatically for us.

core@localhost ~ $ sudo modprobe kheaders
core@localhost ~ $ lsmod | grep -i kheaders
kheaders         	3674112  0

Now that we have the module loaded, we can create the toolbox environment. The /sys/kernel/debug path has to be mounted into the toolbox container to allow BCC to register and unregister kprobes. Please note that we aren’t sharing any volume related to the kernel headers.

core@localhost ~ $ toolbox --bind=/sys/kernel/debug:/sys/kernel/debug

Install the bcc-tools package:

[root@localhost ~]# dnf install bcc-tools xz -y

Now, we can start using any of the tools provided by BCC. Let’s try execsnoop, a tool that monitors the exec syscall, i.e. creation of new processes. Execute some commands in another terminal on the Flatcar host to see how they are traced by the execsnoop tool.

[root@localhost ~]# /usr/share/bcc/tools/execsnoop
PCOMM        	PID	PPID   RET ARGS
ping         	2259   1233 	0 /usr/bin/ping 8.8.8.8
cat          	2260   1233 	0 /usr/bin/cat /dev/null
cat          	2261   1233 	0 /usr/bin/cat /etc/shadow
^C

We can then see how the tool is reporting the different processes that are executed in the host. In this case the BCC tool didn’t load the kernel headers from /lib/modules/$(uname -r)/{source,build}/ but extracted them from /sys/kernel/kheaders.tar.xz into a temporary directory and used them to compile the eBPF code.

CONFIG_DEBUG_INFO_BTF

This option generates BPF Type Format (BTF) information which provides metadata about kernel internal structures. This option is fundamental to use the Compile Once - Run Everywhere (CO-RE) mechanism that allows to run eBPF programs compiled in other kernel versions, decreasing the time they require to be created as they are shipped pre-compiled and it’s not required to compile them in the target machine.

This feature is also present in the Flatcar Container Linux Stable release. We can follow the same steps as above to get an instance running:

$ wget https://stable.release.flatcar-linux.net/amd64-usr/current/flatcar_production_qemu_image.img.bz2
$ bzip2 -d flatcar_production_qemu_image.img.bz2
$ wget https://stable.release.flatcar-linux.net/amd64-usr/current/flatcar_production_qemu.sh
$ chmod +x flatcar_production_qemu.sh
$ ./flatcar_production_qemu.sh

$ ssh -o "UserKnownHostsFile=/dev/null" -o "StrictHostKeyChecking=no" -p 2222 core@localhost
Warning: Permanently added '[localhost]:2222' (ECDSA) to the list of known hosts.
Last login: Mon Apr 19 14:25:31 UTC 2021 on tty1
Flatcar Container Linux by Kinvolk stable (2765.2.2)

In order to try this feature we can use libbpf-tools , a set of BCC-based tools that use libbpf and CO-RE, i.e. they are only compiled once. These tools aren’t packaged for any distro yet, so we’ll need to compile them from source. In this case I’ll compile the tools using Docker. If you don’t want to go through this process, you can just use the quay.io/kinvolk/libbpf-tools image we have prepared.

Let’s start by creating the container image with the libbpf-tools inside.

$ IMAGE=<repo/username/image:tag>
$ mkdir libbpf-tools-container && cd libbpf-tools-container
$ cat <<EOF > Dockerfile
FROM ubuntu:20.04 as builder

RUN set -ex; \
    export DEBIAN_FRONTEND=noninteractive; \
    apt-get update && \
    apt-get install -y build-essential pkg-config clang llvm libcap-dev libelf-dev git && \
    git clone https://github.com/iovisor/bcc/ -b v0.19.0 --recurse-submodules && \
    cd bcc/libbpf-tools/ && \
    make && mkdir /libbpf-tools && DESTDIR=/libbpf-tools prefix="" make install

FROM ubuntu:20.04
RUN set -ex; \
    export DEBIAN_FRONTEND=noninteractive; \
    apt-get update && \
    apt-get install -y libelf-dev
COPY --from=builder /libbpf-tools/bin /usr/bin
EOF
$ docker build . -t $IMAGE
# Push to registry if building on a different host
$ docker push $IMAGE

Now that we have a container image with our tools, we can start a container. It has to be privileged in order to have the permissions needed to load and attach eBPF programs. /sys/kernel/debug has to be shared, as above, to give BCC access to kprobes. Let’s create the container, get an interactive terminal and execute the execsnoop tool. While the execsnoop tool is running, open a different ssh session to the Flatcar host and run some commands there, you’ll see how they are traced.

$ docker run -it --privileged -v /sys/kernel/debug:/sys/kernel/debug $IMAGE
root@1d624982f6c9:/# execsnoop
PCOMM        	PID	PPID   RET ARGS
cat          	1867   1854 	0 /usr/bin/cat /dev/null
ping         	1868   1854 	0 /usr/bin/ping kinvolk.io
^C

CONFIG_BPF_LSM

This option enables the LSM BPF programs that are used to instrument the LSM hooks.

This option is available in the Flatcar Container Linux Beta release and we expect it to be part of Stable on Q2 2021. However, because of some performance degradation the eBPF LSM hook is disabled by default. In order to enable it you should boot the kernel with the lsm=...,bpf command-line parameter .

This is a pretty new feature in the Kernel and we’re not aware of many tools using it. For instance, one use case is the systemd’s RestrictFileSystems property. You can get more details about that feature in our Extending systemd Security Features with eBPF blog post.

What’s next

We are actively looking for new eBPF features in the Linux kernel that could be relevant for our users. If there is any feature that we’re missing and you consider it’s important, don’t hesitate to reach out and create a feature request on our issue tracker .
